TU 32.ЗО.15-0011-05757665-2020 eco-target production standard
«Standart»
The most popular type of eco-targets. It is used both in trap-shooting and sporting.
Production
Since 2001 all types of clay eco-targets have been produced in Lipetsk. Their output has increased significantly, covering the demand both in Russia and the CIS.
We are using production equipment by French (LaPorte) and Spanish (Kromson) manufacturers and in-house process solutions. Every batch of eco-targets undergoes an independent inspection of quality parameters for the compliance with standard requirements in a certified test laboratory and at a trap-shooting range in field conditions.
Ø 110 × 25,5 mm
105 g
— available colors *
Number of eco-targets in a box150
Number of eco-targets on a pallet7200
Box weight with eco-targets (kg)16
Unit load weight (kg)800
Download certificate
pdf, 1 Mb
Ø 110 × 16 mm
115 g
«Rabbit A»
A sporting eco-target imitating a running rabbit. "A" letter in its name designates English type.
— available colors *
Number of eco-targets in a box160
Number of eco-targets on a pallet7680
Box weight with eco-targets (kg)18,65
Unit load weight (kg)927
Download certificate
pdf, 1 Mb
Ø 98,8 × 12 mm
110 g
«Rabbit I»
A sporting eco-target imitating a running rabbit. "И" letter in its name designates Spanish type.
— available colors *
Number of eco-targets in a box150
Number of eco-targets on a pallet7200
Box weight with eco-targets (kg)16,75
Unit load weight (kg)836
Download certificate
pdf, 1 Mb
Ø 110 × 16 mm
120 g
«Rabbit L»
A sporting eco-target imitating a running rabbit. "Л" letter in its name designates Lipetsk type.
— available colors *
Number of eco-targets in a box100
Number of eco-targets on a pallet4800
Box weight with eco-targets (kg)12,25
Unit load weight (kg)620
Download certificate
pdf, 1 Mb
Ø 107 × 10,5 mm
90 g
«Battue»
A sporting eco-target turning while in flight.
— available colors *
Number of eco-targets in a box250
Number of eco-targets on a pallet12000
Box weight with eco-targets (kg)22,75
Unit load weight (kg)1124
Download certificate
pdf, 1 Mb
Ø 110 × 25,5 mm
109 g
«Flash»
A eco-target which, when hit, creates a bright cloud due to special filler. It is mostly used at final stages of competitions.
— available colors *
Number of eco-targets in a box150
Number of eco-targets on a pallet7200
Box weight with eco-targets (kg)16,6
Unit load weight (kg)829
Download certificate
pdf, 1 Mb
Ø 90 × 23,5 mm
70 g
«Midi»
A sporting eco-target, 90 mm in diameter.
— available colors *
Number of eco-targets in a box200
Number of eco-targets on a pallet9600
Box weight with eco-targets (kg)14,25
Unit load weight (kg)716
Download certificate
pdf, 1 Mb
Ø 60 × 18,8 mm
30 g
«Mini»
A sporting eco-target of the smallest diameter, 60 mm.
— available colors *
Number of eco-targets in a box400
Number of eco-targets on a pallet19200
Box weight with eco-targets (kg)12,25
Unit load weight (kg)620
Download certificate
pdf, 1 Mb
* The eco-targets are covered with fluorescent orange paint prepared directly on site using Laporte equipment and technology. The eco-targets can also be unpainted (brown). Other colors are available upon the customer’s pre-order.
All the eco-targets comply with the requirements of ТУ 32.ЗО.15-0011-05757665-2020
State standard specification Р 52909-2008 (with change)
The eco-targets are manufactured on state-of-the-art equipment and are comparable in quality to their foreign equivalents.
The eco-targets are packed in stacks in cardboard crates. In case of truck transportation a unit load is formed from 48 boxes on a wooden pallet (unit load size: 1×1.2×1.4 m). In case of railroad transportation the boxes are stacked in 2-8 layers in 20-feet containers:
| Boxes in a container | Layers of boxes | Weight of cargo in a container (kg) |
|---|---|---|
| 320 units | 2 | 4310 — 6310 |
| 480 units | 3 | 6136 — 9336 |
| 640 units | 4 | 8148 — 11648 |
| 800 units | 5 | 11660 — 14460 |
| 1176 units | 8 | 14060-20650 |
